MSI MSI MPG_Z490_GAM_CARB_WIFI

კოდი: MPG_Z490_GAM_CARB_WIFI

აღწერილობა დამატებითი ინფორმაცია

-უკან დაბრუნება

შემდეგი

ჩამოტვირთვა

ტექნიკური პარამეტრები MSI MSI MPG_Z490_GAM_CARB_WIFI:

მთავარი მახასიათებლები

მთავარი მახასიათებლების სრული სია

Towards	gaming (overclocking)
Form Factor	ATX
Connection type	LGA1200
Processor compatibility	Intel /0th Gen Intel® Core™ and Pentium® Gold / Celeron® processors
Northbridge (chipset)	Intel Z490
The maximum amount of memory	128 GB
Slots PCI-E 16x	3 pcs 3x PCIe 3.0 x16 slots*, support x16/ x0/ x4 or x8/ x8/ x4 mode
Supports CrossFire / SLI	2-Way NVIDIA® SLI™/3-Way AMD® CrossFire™
Sound	7.1
Support software RAID	0, 1, 5, 10
SATA3 (6 Gb / s)	6 ports
LAN (RJ-45)	2.5 Gbps
Wi-Fi	802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
Bluetooth	v5.1 FIPS, FISMA
USB 2.0	6 pcs
Dimensions (HxW)	305 x 244 mm

Main

Towards	gaming (overclocking)
Form Factor	ATX

CPU

For processors	Intel
Connection type	LGA1200
Processor compatibility	Intel /0th Gen Intel® Core™ and Pentium® Gold / Celeron® processors

Chipset

Northbridge (chipset)

Intel Z490

RAM

Connector type	DDR4
DDR4	4 slots
Number of slots	4 slots
Maximum operating frequency	4800 MHz
The maximum amount of memory	128 GB
Support ECC	Supports non-ECC, un-buffered memory
Support for XMP

Video settings

Graphical interface	PCI-E x16 3.0
	PCI-E x1 3.0
Slots PCI-E 1x	2 pcs 2x PCIe 3.0 x1 slots
Slots PCI-E 16x	3 pcs 3x PCIe 3.0 x16 slots*, support x16/ x0/ x4 or x8/ x8/ x4 mode
HDMI Output
Supports CrossFire / SLI	2-Way NVIDIA® SLI™/3-Way AMD® CrossFire™
Display Port

Audio settings

Аudiochip	Realtek ALC1220
Sound	7.1
S/P-DIF	Optical

Connecting drives

Connection interface	SATA 3
	M.2
Support software RAID	0, 1, 5, 10
SATA3 (6 Gb / s)	6 ports

Network interfaces

LAN (RJ-45)	2.5 Gbps
Number of LAN-ports	1
LAN-Controller Model	Realtek RTL8125B
Wi-Fi	802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
Bluetooth	v5.1 FIPS, FISMA

Connection connectors

USB 2.0	6 pcs
USB 3.2 Gen 1	2
USB 3.2 Gen 2	6
M.2 connector	2

Additionally

Features	Chassis Intrusion Header
	RGB LED connector
	CPU fan header
	clear CMOS jumper
	8-pin ATX 12V power connector
	water pump fan connector
	TBT connector
	4-pin ATX 12V power connector
	Front panel audio connector
	CORSAIR connector
	system panel connector /x2
	3-pin RAINBOW LED connectors /x2
	24 pin ATX Power Connector
	System Fan Connector /x6
	Serial port connector
	TPM module connector
	RTD3 connector

Physical

Dimensions (HxW)

305 x 244 mm

შეფუთვის პარამეტრები

სიგანე	350 მილიმეტრი
სიმაღლე	280 მილიმეტრი
სიგრძე	90 მილიმეტრი
წონა	1.91 კგ
მოცულობა	0.0088 მ3

გარანტია

36 თვე

The MPG series brings out the best in gamers by allowing full expression in color with advanced RGB lighting control and synchronization. Experiment on another level of personalization with a front LED strip that provides convenient in-game and real time notifications. With the MPG series, transform your equipment into the center of attention and top leaderboards in style.
