ASUS Motherboard ROG STRIX Z790-A GAMING WIFI II s1700 Z790 4xDDR5 M.2 HDMI DP Wi-Fi BT ATX
| Towards | gaming (overclocking) |
| Form Factor | ATX |
| Connection type | LGA1700 |
| Processor compatibility | Intel Core 13th Generation |
| Intel Core 12th Generation | |
| Intel Core 14th Generation | |
| Northbridge (chipset) | Z790 |
| UEFI BIOS |
 |
| The maximum amount of memory | 192 GB |
| Sound | 5.1 |
| Support software RAID |
0/1/5/10 |
| SATA3 (6 Gb / s) | 4 ports |
| LAN (RJ-45) | 2.5 Gbps |
| Wi-Fi |
7 |
| Bluetooth |
v5.4 |
| USB 2.0 | 6 pcs (4 Type-A задні, 2 передні роз'єми з підтримкою додаткових 4 портів) |
| Main power connector | 24+8 -pin |
| Dimensions (HxW) | 305x244 mm |
| Towards | gaming (overclocking) |
| Form Factor | ATX |
| For processors | Intel |
| Connection type | LGA1700 |
| Processor compatibility | Intel Core 13th Generation |
| Intel Core 12th Generation | |
| Intel Core 14th Generation |
| Northbridge (chipset) | Z790 |
| BIOS | UEFI |
| UEFI BIOS |
|
| Connector type | DDR5 |
| DDR5 | 4 slots |
| Maximum operating frequency | 8000 MHz |
| The maximum amount of memory | 192 GB |
| Support for XMP |
|
| Graphical interface | PCI-E x16 4.0 |
| PCI-E x1 3.0 | |
| PCI-E x16 5.0 | |
| HDMI Output |
|
| Display Port |
|
| Аudiochip | ALC4080 |
| Sound | 5.1 |
| S/P-DIF |
|
| Connection interface | SATA 3 |
| M.2 | |
| Support software RAID |
0/1/5/10 |
| SATA3 (6 Gb / s) | 4 ports |
| LAN (RJ-45) | 2.5 Gbps |
| Number of LAN-ports | 1 |
| Wi-Fi |
7 |
| Bluetooth |
v5.4 |
| USB 2.0 | 6 pcs (4 Type-A задні, 2 передні роз'єми з підтримкою додаткових 4 портів) |
| M.2 connector | 5 |
| Features | Thermal sensor connector |
| TPU switch | |
| S/PDIF out header | |
| Clear CMOS button | |
| RGB Headers | |
| CPU OPT Fan connector | |
| AIO Pump header | |
| CPU fan header | |
| Front panel audio connector | |
| BIOS Flashback | |
| Synchronization backlight Asus Aura Sync | |
| DTS® Sound Unbound | |
| ROG CPU-Z | |
| ASUS Q-Design | |
| ASUS Thermal Solution | |
| ASUS Exclusive Software | |
| ASUS EZ DIY | |
| Fan Xpert4 | |
| SafeDIMM slot | |
| FlexKey | |
| Addressable Gen 2 header | |
| AI Suite 3 | |
| Digi+ VRM | |
| Front Panel Header | |
| Extreme Engine Digi+ | |
| Chassis Fan headers | |
| Box Contains | SATA Cable /x2 |
| Quick Guide | |
| M.2 Rubber Package | |
| M.2 Q-Latch Package | |
| Cable ties pack | |
| ROG key chain | |
| ROG Strix stickers | |
| Wi-Fi Antenna | |
| Thermal pad for M.2 | |
| M.2 backplate Rubber | |
| M.2 backplate Q-Latch package |
| Main power connector | 24+8 -pin |
| Dimensions (HxW) | 305x244 mm |
| გარანტია | 36 თვე |
| სიგანე | 360 მილიმეტრი |
| სიმაღლე | 70 მილიმეტრი |
| სიგრძე | 270 მილიმეტრი |
| წონა | 2.26 კგ |
| მოცულობა | 0.0068 მ3 |
Q-ANTENNA
With Q-Antenna, attaching a WiFi antenna to your PC is now easy and fast. Instead of slowly rotating two fasteners until they finally lock in, they just snap into place. Less hassle, and more consistent performance.
PCIE SLOT Q-RELEASE
A physical button unlocks the first PCIe slot’s security latch with one press, greatly simplifying the process of detaching a PCIe card from the motherboard when it’s time to upgrade to a new GPU or other compatible device.
Robust power delivery, breakneck DDR5 memory, speedy storage, and comprehensive cooling elevate any build with the ROG Strix Z790-A II at its center.
AI OVERCLOCKING
Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation.
PCIE 5.0
The top PCIe 5.0 x16 SafeSlot is well-equipped for the increased size and bandwidth of next-gen graphics cards. Zippy storage options abound with four PCIe 4.0 M.2 slots, all featuring robust heatsinks to maximize performance.
LEADING CONNECTIVITY
Next-gen connectivity and low-latency networking are hallmarks of the ROG ecosystem, and the Strix Z790-A II delivers both of them in full. Joining them is an advanced audio solution for immersive sound so you can pick out the slightest cues and nuances.
DDR5 DOMINATION
ROG has a long legacy of flexing the fastest memory performance, and DDR5 is no outlier. Thanks to improved signal routing, now enthusiast-grade kits have been driven far beyond the 8 GT/s mark on the Strix Z790-A II, and who knows how far future DIMMs can go? Seasoned veterans can test their mettle by tinkering with the extensive array of tuning options in the UEFI.
LEADING CONNECTIVITY
Next-gen connectivity and low-latency networking are hallmarks of the ROG ecosystem, and the Strix Z790-A II delivers both of them in full. Joining them is an advanced audio solution for immersive sound so you can pick out the slightest cues and nuances.
WIFI 7
With Multi-Link Operation (MLO), WiFi 7 can outperform WiFi 6E to deliver faster speeds, higher reliability and increased data transfer efficiency.
Intel 2.5Gb Ethernet
Low-latency gaming, speedy file transfers, and high-resolution video streaming are among the many perks of onboard Intel 2.5 Gbps Ethernet.
USB 20GBPS
The Strix Z790-A II comes loaded with two USB 20Gbps Type-C® connectors for speedy data transfers up to 20Gbps. One is a port on the rear I/O; the other can be attached to the chassis front panel and it also features Power Delivery (PD) 3.0 technology to quickly charge devices up to 30W.
SUPREMEFX
ROG SupremeFX is a unique blend of hardware and software technologies that provide superior audio. The Strix Z790-A II implementation features the ALC4080 codec for high-resolution playback up to 32-bit/384 kHz across all channels. Front-panel output is streamed through the integrated Savitech amplifier that can drive high-fidelity acoustics to a wide variety of speakers and headsets.
