Towards | gaming (overclocking) |
Form Factor | mini-ITX |
Connection type | AM5 |
Northbridge (chipset) | AMD X870 |
UEFI BIOS |
![]() |
The maximum amount of memory | 96 GB |
SATA3 (6 Gb / s) | 2 ports |
LAN (RJ-45) | 2.5 Gbps |
Wi-Fi |
![]() |
Bluetooth |
![]() |
USB 2.0 | 5 pcs (3 задніх Type-A, 2 роз'єми з підтримкою 3 USB 2.0 портів - ROG FPS Card) |
Dimensions (HxW) | 170 x 170 mm |
Towards | gaming (overclocking) |
Form Factor | mini-ITX |
For processors | AMD |
Connection type | AM5 |
Northbridge (chipset) | AMD X870 |
BIOS | UEFI |
UEFI BIOS |
![]() |
Connector type | DDR5 |
DDR5 | 2 слота |
The maximum amount of memory | 96 GB |
Graphical interface | PCI-E x16 4.0 |
PCI-E x16 5.0 | |
HDMI Output |
![]() |
Connection interface | SATA 3 |
M.2 | |
SATA3 (6 Gb / s) | 2 ports |
LAN (RJ-45) | 2.5 Gbps |
Number of LAN-ports | 1 |
Wi-Fi |
![]() |
Bluetooth |
![]() |
USB 2.0 | 5 pcs (3 задніх Type-A, 2 роз'єми з підтримкою 3 USB 2.0 портів - ROG FPS Card) |
USB | 18 pcs (10 задніх; 3 фронтальних; 2 - ROG STRIX HIVE II; 3 - ROG FPS Card) |
USB 3.2 Gen 1 | 1 /(фронтальний роз'єм з підтримкою 2 додаткових портів) |
USB 3.2 Gen 2 | 8 /(4 задніх Type-A, 1 задній Type-C, 1 фронтальний Type-C, ROG STRIX HIVE II: 1 x Type-A + 1 x USB Type-C) |
USB 3.2 Type-C | 5 pcs (2 задні USB4 Type-C, 1 задній Type-C, 1 передній конектор Type-C; ROG STRIX HIVE II: 1 x USB Type-C) |
M.2 connector | 2 |
Features | Clear CMOS button |
BIOS Flashback | |
Synchronization backlight Asus Aura Sync | |
ROG CPU-Z | |
ASUS Q-Design | |
ASUS Thermal Solution | |
ASUS Exclusive Software | |
ASUS EZ DIY | |
ROG Patented Pre-mounted I/O Shield | |
Fan Xpert4 | |
SafeDIMM slot | |
FlexKey | |
Addressable Gen 2 header | |
ASUS GlideX | |
HWiNFO | |
GameFirst | |
Dolby Atmos | |
Box Contains | SATA Cable /x2 |
M.2 Rubber Package | |
M.2 Q-Latch Package | |
Cable ties pack | |
ROG key chain | |
ROG Strix stickers | |
Panel Cable | |
ROG USB 2.0 splitter cable | |
Quick start guide | |
ASUS WiFi Q-Antenna | |
ROG FPS Card | |
ROG STRIX HIVE II | |
USB Type-C |
Dimensions (HxW) | 170 x 170 mm |
სიგანე | 280 მილიმეტრი |
სიმაღლე | 110 მილიმეტრი |
სიგრძე | 220 მილიმეტრი |
წონა | 1.78 კგ |
მოცულობა | 0.0068 მ3 |
გარანტია | 36 თვე |
ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits.
AI COOLING II
Balance the thermals and acoustics of any build with a single click.
AI NETWORKING II
AI Networking II combines intelligent technologies to continuously optimize network performance, provide trustworthy and seamless connectivity, and unleash the full speed of WiFi 7*.
Dynamic OC Switcher
Dynamic OC Switcher maximizes CPU performance by letting you set current and temperature thresholds to automatically switch between a manual overlock for heavy multithreaded workloads and Precision Boost Overdrive for single-threaded tasks. The latest Overclocking Load Guard has an enhanced instantaneous current protection mechanism to prevent users from experiencing system crashes during overclocking.
Core Flex empowers you to smash limits farther than ever before by letting you control clock, power, and thermals in creative new ways. In its simplest form, you can maximize base clock during lighter loads and set breakpoints to gradually reduce CPU core frequency as temperature or current increases. But the system is extremely adaptable, supporting multiple user-controlled functions that can manipulate power, current, and temperature limits independently so that you can bend CPU performance to your will.
PBO ENHANCEMENT
AMD Precision Boost Overdrive (PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD's algorithm can leverage the motherboard's robust power solution to ramp up performance even higher.
DDR5 DOMINATION
The Strix X870-I is primed and ready for enthusiast-grade kits courtesy of vast AMD EXtended Profiles for Overclocking (EXPO) support.
AEMP
ASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules.
ROG STRIX HIVE II
The ROG Hive II is an exclusive accessory designed to deliver user-friendly access to hardware and software features.
ROG FPS Card
The ROG FPS card groups I/O onto a vertically-mounted card, saving valuable motherboard space and tidying cable management.
BIOS Q-DASHBOARD
Simplify your motherboard configuration with BIOS Q-Dashboard. Its intuitive visual representation of hardware connections and corresponding BIOS settings takes the complexity out of setting up your system. Upgrade now, and discover the power of BIOS Q-Dashboard to easily and efficiently enhance your computing setup.
UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.
Dolby ATMOS
ROG and Dolby have partnered to bring superior gaming audio quality to users. Dolby Atmos expands on traditional surround sound systems by adding height channels, which enables immersive three-dimensional audio to be perceived from above, below and around the listener.
UNDENIABLY ROG STRIX
The I/O shield and M.2 heatsink feature a perforated metal mesh that can either reflect the glow of internal RGB components or blend seamlessly into the shadows of a stealthy build. The cyber-style text and sharp, angular details firmly establish this motherboard as a member of the ROG Strix family.
COOLER COMPATIBILITY
ASUS AIO coolers offer robust performance, high overclocking potential, bold aesthetics and customizable functionality for X870 motherboards, empowering you to build your dream gaming rig.
